Schüco Tilt Before Turn Windows

Quality AWS70 HI Schüco Tilt Before Turn Windows – designed & manufactured in the UK

...

The Schüco AWS 70 HI combines high quality with the highest requirements of design, comfort, security and energy efficiency. Stylish in appearance, with slim profile sightlines which allow more space for glass and natural light to flow through.

All windows are fitted with modern hardware to complement the aesthetics of your home.



Key features of Schüco Tilt Before Turn Windows

  • Slim aluminium sections means more glass and more light
  • Choose from a wide choice of colours
  • Contemporary square bead
  • Windows can open outwards or inwards and with a tilt option for ease of cleaning
  • Handles in Anodised Silver, Black or White
  • For your safety and security we fit key locking handles to all of our windows
  • 70mm deep frame that fixes to the wall of your property
  • U-Value 1.5 W/(m²K)
  • PAS24 tested

Options

  • Windows can be side hung, top hung or fixed, please visit KAT’s separate product page
  • Cills can be 85mm, 150mm or 190mm deep with a 25mm platform on cills


General Description
The Schuco AWS 70 HI Tilt Before Turn Window offers a high level of thermal insulation to keep your home warm, whilst the narrow face widths allow more room for glass and therefore more light into your home. They can either be opened inwards or tilted at the top to allow for ventilation and ease of cleaning the outside. All Tilt Before Turn windows are stylish and are fitted with modern hardware and are available in a vast array of finishes.
Manufacturer
KAT – a Schuco Partner
Materials
Aluminium
Specification
Frame depth 70mm front to back
Tilt and Turn Sash
Min sash width 600mm
Max sash width 1500mm
Min sash height 700mm
Max sash height 2000mm

Maximum sash weight 150kg
Bead
Square
Cills
85mm deep
150mm deep
190mm deep

25mm platform on all cills
Hardware
Cranked handle in Anodised Silver as standard.
White and Black available to order
Glazing
‘Planitherm Total +’ low emissivity 28mm sealed units
Clear glass, soft coat lamination, argon filled units.
Can accommodate glazing up to 34mm.
Security and Performance
Espagnolette window locks with key locking handles
Option for windows to conform to PAS24
U-Value 1.5
Air permeability Class 4
Water Tightness 9A
Wind Load Resistance C5/B5
Colours
Any RAL colour, including dual colours.

Gallery

...

KAT  windows are manufactured using the latest technology, machinery and manufacturing processes. Each window is then hand-finished and checked for quality in our factory in Newhaven.The Tilt Before Turn facility allows easy cleaning of the outside of the windows.

KAT manufacture Schüco Bifold doors and Patio doors in colours to match Schüco windows, each carrying a 10 year guarantee.



Material Information

...

Many people choose Schuco Aluminium Tilt Before Turn Windows for reasons of durability and ease of maintenance in addition to the slim sightlines and contemporary design.



Materials

Accessories

...

Hardware for Schuco Windows can be manufactured in austenitic steel which is a marine grade finish for coastal applications.

All hardware in KAT Schüco Windows is bespoke to the product, no generic industry hardware is used.

Check out the finishes on our handles because it is attention to detail that helps make this unique product range so exciting.

Available in:

  • Anodised Silver
  • Black
  • White


Accessories

Safety & Security

...

All Schuco Windows are manufactured so that the gaps between the sash and frame are small enough to make it difficult for a would be intruder to gain access. In addition to this, key locking handles are fitted to all windows, as standard.



Safety & Security

Colour Options

...

A little time and care with your choice of colour is advised and your selection should be influenced by your style of property, surrounding architecture or the doors within your home.

KAT Schüco Tilt Before Turn Windows are available in a wide range of RAL colours. Our 3 standard colours are White gloss, Anthracite Grey and Black and these are available with a short delivery time. Call into our Showroom in either Newhaven or Macclesfield and we can show you a colour chart demonstrating each of the RAL colours available.



Colours

Questions?
...contact us today!

If you wish to find your KAT design partner, have any questions or would like to discuss our premium range of products then please contact us.
